DC-DC Step Down Buck Module Lm2596HV
SKU
MD-00649
PKR720.00
Quantity: 0
DC-DC Step Down Buck Module Lm2596HV
- Buy 3 for PKR684.00 each and save 5%
- Buy 10 for PKR662.40 each and save 8%
Categories: Power Module, Voltage Regulator
This is an LM2576HV(High Voltage Input/Output upto 60V) DC-DC buck converter step-down power module with high-precision potentiometer for adjusting output voltage, capable of driving a load up to 3A with high efficiency. When the output current required is greater than 2.5A(10W) an external heatsink is suggested.
SPECIFICATIONS:
- Module Properties: non-isolated constant voltage module
- Rectification: non-synchronous rectification
- Input voltage: 4.5V-60V
- Output Voltage(Less than input): 1.3V-30V
- Output current: 3A maximum
- Conversion efficiency: 92% (maximum)
- Switching frequency: 52KHz
- Output ripple: 50mV (maximum) 20M-bandwidth
- Load regulation: ± 0.5%
- Voltage regulation: ± 2.5%
- Operating temperature: -40 ℃ to +85 ℃
PACKAGE INCLUDES:
- 1 X DC-DC Step Down Buck Module Lm2596HV
| Part Number | Lm2596HV |
|---|---|
| Weight (KG) | 0.020000 |
| Manufacturer | Made in China |
| Product Availability | In Stock |
| Voltage (Min) | 5V |
| Voltage (Max) | 6V |
| Output Voltage | 1.25V~30V |
| Power | NA |
| Current (A) | 3 |
| Frequency | NA |
| Load Cell (kg) | NA |
| Output Type | Digital |
| Range | 1.25V~30V |
| Temperature Range (Min) | -40°C |
| Operating System | NA |
| Resistance Value (Ohm) | NA |
| Baud Rate | NA |
| Interface | NA |
| Num of Pin's | NA |
| Diameter | NA |
| Size (mm) | NA |
