Creality 3D - Creality 3D Printer DIY Kit CR-10-S4 Large Printing Size 400x400x400mm
Product features
- Half-assembled, just need 10 minutes to assemble, solve the problem of high freight
- Large printing size: 400*400*400mm or 15.8"x15.8"x15.8"
- Patent technology for XYZ aluminum V-slot bearing + precision roller with high positioning accuracy to make it run smoothly and get higher quality product.
- Simple design, easy to make, to avoid the cumbersome installation.
- Industrial-grade PCB can continuously print for about 200 hours (under ideal conditions), with matures printing technology and stable performance.
Product description
Patent MK10 nozzle extrusion structure can print more printing material without block.
Electronic control host was separated from the printing body, in order to meet the needs of refitting printing size to various specifications according your imagination.
Product Parameters
PrintingSize：400*400*400mm or15.8"x15.8"x15.8"
Printing accuracy：±0.1mm
Nozzle Diameter：Standard 0.4mm(can be changed to 0.3/0.2mm)
Printing Speed：Normal: 80mm/s, Max.: 200mm/s
Materials：1.75mm PLA, ABS, TPU, Copper, Wood, Carbon Fiber, Gradient Color etc.
Software supporting : PROE, Solid-works, UG, 3d Max, Rhino 3D design software, etc.
Format : STL, OBJ, G-Code, JPG
Printing Method: SD card(off-line), contact to the PC(on-line)
Body Structure: Imported V-Slot Aluminum Bearings.
Operating System: Linux,Windows,OSX
Printing Software:CURA,simplify 3D,Repetier-Host
Product Size: 590*700*615mm
Package Size: 760*650*330 mm
Package Weight: 18.2kg
Packing List:
Bottom Frame x1PCS
Vertical Frame x1PCS
Power supply Box x1PCS
Build Plate Tape x1Roll
Filament Spool holder x 1Set
Tie x 1Set
Cutting Nipper x1PCS
Wrench x1 Set
Screw x 2Bag
Revoming Toolx 1PCS
Power Linex1PCS
USB Cablex 1PCS
Teflon Tube x1PCS
SD Card x 1PCS
Limit Switch x 1PCS
Z axis Stator x 1PCS
0.4mm Nozzle x 1PCS
Nozzle Clearer x 1PCS
200g Filament x 1Roll
| Part Number | CR-10-S4 |
|---|---|
| Weight (KG) | 14.000000 |
| Manufacturer | Creality3D |
| Model | CR-10-S4 |
| Voltage (V) | NA |
| Output Voltage | NA |
| Maximum Printing Size | NA |
| Nozzle Type | NA |
| Filament Diameter | 1.75mm |
| Operating System | NA |
| Interface | NA |
| Support Material | NA |
