Color TFT Touch LCD Display Screen 128x160 for Arduino - ST7735T

SKU
MD-01901
PKR5,180.00
Quantity: 3
It is a high-definition 1.8 inch TFT LCD liquid crystal display module.Its driver chip is ST7735 and SPI output.

Feature:

  • Touch screen
  • TFT LCD display
  • SPI output
  • High Definition
  • Adjust display direction
  • RGB display

Parameter:


  • Work Voltage:3.3V
  • Display Size:1.8inch
  • Resolution:128*160
  • Interface Type:SPI output
  • Driver Chip:ST7735
  • Number of Pins:12
  • Operating Temperature:-20℃~70℃
  • Operating Humidity:5%~95%RH
  • Model Size:56*35.5*13mm

Pinouts

  • GND:Power negative
  • VCC:Input power supply positive 3.3V
  • SCL:SPI clock terminal
  • SDA:SPI data terminal
  • RES:Display reset terminal,low level reset
  • DC0:Instruction register
  • DC1:Select data register
  • BLK:Blacklight control(Low level turns off the backlight)
  • MISO:Serial clock
  • CS1:Enable signal
  • CS2:Touchscreen enable signal
  • PEN:Touch trigger output
  • NC:Reserve
Part Number ST7735T
Product Availability In Stock
