The Power of Thermal In Your Hand
TECHNICAL SPECIFICATIONS:
- ♦ 1st Thermal Imaging Smartphone Powered by FLIR™
- ♦ 5M Waterproof With unique Lockdown Switch
- ♦ Beyond Military Specification Drop-Proof to 1.8M
SEE THE WORLD DIFFERENTLY
The first of its kind, the Cat® S60 gives you live thermal imaging expertise direct from your smartphone. Utilising MSX Technology exclusive to FLIR, this rugged smartphone captures shareable clear thermal imagery, video and even timelapse footage. Multiple spot meters allow you to retroactively pinpoint a temperature in your image while the thermal imagery technology is capable of penetrating even obscurants like smoke.
KEEP COOL IN TOUGH SITUATIONS
Drop-proof to 1.8m and reinforced with a strengthened die cast frame, the Cat® S60 exceeds even military specifications, making it the perfect companion to those living even the most rugged of lifestyles.
| Battery | Type |
Non-removable Lithium Ion with Quick Charge 2.0
|
| Capacity | 3800 mAh | |
|
Talk Time*
|
up to 30 hours*
|
|
|
Standby Time*
|
up to 43 days*
|
|
| Display |
Display Type
|
Super bright 4.7″ a-Si AHVA, HD, 1280×720
|
|
Display Cover
|
Corning® Gorilla® Glass 4
|
|
| Camera |
Main/Rear
|
13MP Autofocus + FLIR Thermal Camera
|
| Front | 5MP | |
|
Video Capture
|
Yes, 1080p, 30fps
|
|
| Connectivity |
Audio Jack
|
3.5mm
|
|
Bluetooth®
|
4.1
|
|
| NFC | Yes | |
|
Wi-Fi®
|
802.11 b/g/n
|
|
| USB |
micro-USB 2.0, USB-OTG
|
|
|
Sim Type
|
Nano sim (Dual Sim)
|
|
| GPS |
GLONASS, GPS, aGPS, Beidou
|
|
| Data Speed |
Maximum Downlink Data Rate
|
150Mbps
|
|
Maximum Uplink Data Rate
|
50Mbps | |
| Memory |
ROM Flash
|
32GB |
| RAM | 3GB | |
|
Extended Storage
|
microSD™ up to 128GB
|
|
Multimedia |
Audio Playback
|
AAC, AAC+, eAAC+, AMR-NB, AMR-WB, MP3, MIDI, OGG, WAV, FLAC, MKV
|
|
Audio Recording
|
AMR-NB, AMR-WB, AAC, AAC+, eAAC, WAV
|
|
|
Video Playback
|
H.263, H.264, H.265, MPEG4, VP8, VP9
|
|
|
Video Recording
|
AMR-NB, AMR-WB, AAC, AAC+, eAAC, WAV
|
|
Network |
2G |
GSM/GPRS/EDGE
|
|
2G Frequencies
|
850/900/1800/1900 MHz
|
|
| 3G |
WCDMA/UMTS/HSPA/HSPA+
|
|
|
3G Frequencies
|
850/900/2100 (ROW variant) | 850/AWS/1900 (North America variant)
|
|
| 4G |
Yes, Cat 4
|
|
|
4G Bands (LTE)
|
1, 3, 7, 8, 20 (ROW variant) | 2, 4, 5, 7, 12, 17 (North America variant)
|
|
Processor |
Processor Type
|
Qualcomm MSM8952-3 (4 x 1.5GHz + 4 x 1.2GHz)
|
|
Platform/OS
|
Android™ 6.0 Marshmallow
|
|
Rugged |
IP Rating
|
IP68 Certified
|
| Waterproof |
Up to 5m for 60 mins
|
|
|
Dust Proof
|
Impervious to dust
|
|
|
Drop Test
|
Up to 1.8M (6 ft)
|
|
|
Military Standard
|
MIL-SPEC 810G, Shock and Drop,
Operating Temp: -25°C (-13°F) to 55°C (131°F),
Category 4 vibration
|
|
Sensors |
Accelerometer | Yes |
|
Proximity Sensor
|
Yes | |
|
Ambient Light Sensor
|
Yes | |
|
Compass
|
Yes | |
| Size/Weight | Size |
147.9 x 73.4 x 12.66 mm
|
| Weight | 223g |
