4-Degrees of Freedom Robotic Arm AL5D (Hardware Only)

The Lynxmotion AL5D 4 Degrees of Freedom Robotic Arm (Hardware Only) line of robotic arms deliver fast, accurate, and repeatable movement. Each arm features Lynxmotion Base Rotate Kit (no servos) , single plane shoulder, elbow, wrist motion and a functional gripper. The wrist rotate feature, which comes in a Lynxmotion Wrist Rotate Upgrade (Light Weight) or Lynxmotion Wrist Rotate Upgrade (Heavy Duty) option, is sold separately. Lynxmotion designed an affordable system based on a time tested, rock solid design that will last and last. Add your own servos and electronics to complete the kit. The aluminum robotic arm is made from Lynxmotion's Servo Erector Set components for the ultimate flexibility and expandability. The kit consists of black anodized aluminum brackets, Aluminum tubing and hubs, custom injection molded components, and precision laser-cut Lexan components.

SPECIFICATIONS:

1. No of axis = 4 + Gripper; Wrist Rotate upgrade optional
2. Range of motion per axis = 180 degrees
3. Wrist rotate option sold separately
4. 4 + 1 Degree of freedom robotic arm
5. 10.25” median reach
6. Servo Motors sold separately
7. Electronics and software sold separately
8. Wrist rotate option sold separately

RELATED DOCUMENTS:

1. User Manual.

RELATED VIDEO:

DIMENSIONS:

1. Distance (base-to-elbow axis) = 5.75"
2. Distance (elbow-to-wrist axis) = 7.375"
3. Height (arm parked) = 7.25"
4. Height (reaching up) = 19.00"
5. Median forward reach = 10.25"
6. Gripper opening = 1.25"

PACKAGE INCLUDES:

1. 1 X 4-Degrees of Freedom Robotic Arm AL5D (Hardware Only)
