4-Channel Opto Isolated Relay Board (5V 10A)
SKU
CM-00080
PKR 980.00
High Quality 4-Channel Optocoupler Isolated Relay Board to be used with any Microcontrtoller.
🔥 High Demand Allocation:
4 Units
⚠️ Limited Quantity Remaining
Categories: Relays, Switching Module
High Quality 4-Channel Optocoupler Isolated Relay Board to be used with any Microcontrtoller.
Specification:
4-channel relay output modules, relay output contacts 250V 10A. Input IN1, IN2, IN3, IN4, the signal line LOW effective. VCC, GND power input, can relay a separate power supply relay power input of JD-VCC.
Relay output contacts: 250v 10A.
USE: Connect 5V and Gnd to Relay Board, Connect Microcontroller output pins to IN1, IN2, IN3, IN4.
Package size:
10cm x 10cm x 10cm (3.94in x 3.94in x 3.94in)
NOTE: The digital inputs from Microcontroller are Active LOW: The relay actuates and an LED lights when the input pin is HIGH, and turns off on LOW.
Specification:
4-channel relay output modules, relay output contacts 250V 10A. Input IN1, IN2, IN3, IN4, the signal line LOW effective. VCC, GND power input, can relay a separate power supply relay power input of JD-VCC.
Relay output contacts: 250v 10A.
USE: Connect 5V and Gnd to Relay Board, Connect Microcontroller output pins to IN1, IN2, IN3, IN4.
Package size:
10cm x 10cm x 10cm (3.94in x 3.94in x 3.94in)
NOTE: The digital inputs from Microcontroller are Active LOW: The relay actuates and an LED lights when the input pin is HIGH, and turns off on LOW.
| Part Number | NA |
|---|---|
| Manufacturer | Made in China |
| Weight (KG) | 0.300000 |
| Product Availability | In Stock |
