STMicroElectronics: Embedded Discovery Board 32-Bit ARM Cortex-M4 - STM32F429I-DISC1

The STM32F429 Discovery kit (32F429IDISCOVERY) allows users to easily develop applications with the STM32F429 high-performance MCUs with ARM®Cortex®-M4 core.It includes an ST-LINK/V2-B embedded debug tool, a 2.4" QVGA TFT LCD, an external 64-Mbit SDRAM, an ST MEMS gyroscope, a USB OTG micro-AB connector, LEDs and push-buttons.

SPECIFICATIONS:

1. STM32F429ZIT6 microcontroller featuring 2 Mbytes of Flash memory, 256 Kbytes of RAM in an LQFP144 package
2. On-board ST-LINK/V2-B
3. USB functions: debug port, virtual COM port, mass storage
4. Board power supply: through the USB bus or from an external 3 V or 5 V supply voltage
5. 2.4" QVGA TFT LCD
6. 64-Mbit SDRAM
7. L3GD20, ST MEMS motion sensor 3-axis digital output gyroscope
8. Six LEDs: LD1 (red/green) for USB communication, LD2 (red) for 3.3 V power-on
9. Two user LEDs: LD3 (green), LD4 (red)
10. Two USB OTG LEDs: LD5 (green) VBUS and LD6 (red) OC (over-current)
11. Two push-buttons (user and reset)
12. USB OTG with micro-AB connector
13. Extension header for LQFP144 I/Os for a quick connection to the prototyping board and an easy probing
14. Comprehensive free software including a variety of examples, part of STM32CubeF4 package or STSW-STM32138 for legacy standard libraries usage

RELATED DOCUMENTS:

1. Datasheet.
2. User Manual.
3. Software User Manual.

PACKAGE INCLUDES:

1. 1 X 32-Bit ARM Cortex-M4 Embedded Discovery Board STM32F429I-DISC1
