Relay SRD-12VDC-SL-A (4Pin) 10A
PKR 80.00
Only 6 left
SKU
MD-00055
Widely used in remote control, communication, automatic control, electronic equipments, etc.
The relay plays the role as a protector or a circuit switch. It can protect your electric equipments very well.
Specification:
1) Contact Form: 1A 1C
2) Contact material: Silver Alloy
3) Contact Resistance: 100mΩ(1A 6VDC)
4) Contact Rating: 15A 14VDC/125VAC,10A 30VDC/250VAC
5) Max.Switching Current: 15A,10A
6) Max.Switching voltage: 250VAC/30VDC
7) Electrical life: 100000 ops
8) Mechanical Life: 10000000 ops
9) Initial insulation resistance: 100MΩ
10) Dielectric strength: 1500VAC/750VAC
11) Operate Time: ≤10ms
12) Release Time: ≤5ms
13) Ambient temperature: -40°C~+105°C
14) Termination: PCB
15) Construction: Sealed
16) Coil power: 0.36w,0.45w,0.6w,0.8w
17) Unit Weight: 10g
1) Contact Form: 1A 1C
2) Contact material: Silver Alloy
3) Contact Resistance: 100mΩ(1A 6VDC)
4) Contact Rating: 15A 14VDC/125VAC,10A 30VDC/250VAC
5) Max.Switching Current: 15A,10A
6) Max.Switching voltage: 250VAC/30VDC
7) Electrical life: 100000 ops
8) Mechanical Life: 10000000 ops
9) Initial insulation resistance: 100MΩ
10) Dielectric strength: 1500VAC/750VAC
11) Operate Time: ≤10ms
12) Release Time: ≤5ms
13) Ambient temperature: -40°C~+105°C
14) Termination: PCB
15) Construction: Sealed
16) Coil power: 0.36w,0.45w,0.6w,0.8w
17) Unit Weight: 10g
| Part Number | NA |
|---|---|
| Manufacturer | Made in China |
| Weight (KG) | 0.010000 |
